ID-65 laboratory disc pulverizer
Purpose:
For dry grinding of samples in periodical mode.
Delivery set:
- Disc pulverizer assy.
- Auxiliary equipment: operating console.
- Fast wearing parts: discs*
- * steel or corundum discs can be supplied as option.
Назад
Disk pulverizer ID-65
Price on request
Description
Specifications
| Specification | ID-65 |
| Feed size, mm, up to | 2 |
| Product size, mm | d50 <0.05 |
| Opening size range, mm | 0,05 - 0,5 |
| Throughput for sample comminution to a particle size of 0.05 mm*, kg/h | 0,2-0,3 |
| Motor power, kW | 0.37 |
| Overall dimensions, mm, up to | |
| Length | 370 |
| Width | 200 |
| Height | 270 |
| Mass, kg | 19 |
*depending on the operating aperture size and processed material properties.
STOCK: Time of manufacture to order - 2.5 months.
