Disk pulverizer ID-250M

On order

Price on request

Description

Purpose:

The pulverizer is designed for dry fine grinding of brittle materials of various hardness and strength in continuous or periodical mode. The pulverizer has the damage prevention system in case of uncrushable object ingress.

M and MS - equipped with a block of protection against ingress of non-shatterable material, and also have a V-belt feed.

MS-has a more convenient access to the crushing chamber for cleaning

Delivery set:

Disc pulverizer assy.
Auxiliary equipment: operating console.
Fast wearing parts: discs.

For purchasing the equipment or for more detailed information, don’t hesitate to contact us +7 (812) 331-02-42.

Specifications

*Specification*	ID-250М
Feed size, mm, up to	12
Product size, mm	d50 < 0.2
Opening size range, mm	0.2 - 5
Efficiency (depending on the operating aperture size and processed material properties), kg/h	50-300
Motor power, kW	5.5
*Overall dimensions, mm, up to*
Length	1100
Width	610
Height	1200
Mass, kg	330

Stock: The pulverizers are available from stock.
