Chute sample splitter SR 5-48 (943RM) riffle

On order

Price on request

Description

The riffle is designed for loose sample splitting into two components equal by mass and by content.

For purchasing the equipment or for more detailed information, don’t hesitate to contact us +7 (812) 331-02-42.

Specifications

*Specification*	943RM riffle
Bar width, mm	5
Number of bars, pcs.	48
Total width of riffle surfaces, mm	240
Number of riffles with the width of:
5 mm	48
10 mm	24
15 mm	16
20 mm	12
30 mm	8
40 mm	6
Size of the piece for splitting with the riffle width of (mm):
5 mm	3.5
10 mm	7
15 mm	10.5
20 mm	14
30 mm	21
40 mm	28
Bowl size, l	4.5
Riffle widths used, mm	5, 10, 15, 20
*Overall dimensions, mm*
Length	320
Width	280
Height	420
Mass, kg	15

Stock: time of manufacture to order - 2 months.
